Turck - SI-QM100DMSH
| Manufacturer | Turck |
|---|---|
| Part Number | SI-QM100DMSH |
| Inner Code | 765644 |
| Description | Machine Safety — Safety switch with protection lock |
| Technical specification | ID:3077751 Function Protection lock security key Output function 2 x NC contacts, Potential Free Contact rating 4A/230V AC-15 Rated insulation voltage 250 V Conventional thermal current 5 A Impulse resistance voltage 2.5 kV Protection class I Design Rectangle Housing material Metal, Die-cast aluminum alloy Mechanical life 1 * 106 Switching cycles B10d value is 2*106 Switching cycles Cascadable no Electrical connection Terminal connection, with cable gland terminal box Ambient temperature -30…+60 °C IP Rating IP67 Special features Lockable Wash down Tests/approvals PL acc. to DIN EN 13849-1:2008 Category acc. to DIN EN 13849-1:2008 4 SIL according to IEC 61508 3 Encoding level/tamper protection Low |
| Weight | 1 |
Please contact us to request a price quote for Turck - SI-QM100DMSH, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
