Turck - SI-LS42DSJ
| Manufacturer | Turck |
|---|---|
| Part Number | SI-LS42DSJ |
| Inner Code | 766619 |
| Description | Interlock Body, Spring Locking |
| Technical specification | Solenoid Voltage: 24 V ac/dc Contact Configuration: 3 NC; 1 NC Dimensions: 170 x 43 x 45 mm; Plastic Housing Switch Style Contact Device Type Mechanical - Sensor Primary Housing Material Thermoplastic In-Series Diagnostics No Locking Mechanism Power Unlock Device Size 170 x 43 x 45 Device Shape Rectangular Min Op. Temperature (°C) -25 Max Op. Temperature (°C) 70 IP Rating IP67 PL Rating PL e SIL Rating SIL CL 3 Safety Category Cat 4 SISTEMA B10d = 2 million Actuator (Safety) Contacts 3 NC Monitor (Locked) Contacts 1 NC Output Type Contacts Connection Type Wiring Chamber Feature: Lockable Yes Feature: Quick Disconnect No Operating Voltage 24 V ac/dc Rated Operating Current 4.4 VA In Rush Power Consumption (VA/s) 12 VA (0.2 s) Mechanical Life (operations in millions) 1 Auxilliary Output No Power Consumption (W/VA) 4.4 VA Extraction Force (N) 1500 Coding Level/Tamper Resistance Low |
| Weight | 1 |
