Turck - SDPB-10S-0005
Manufacturer | Turck |
---|---|
Part Number | SDPB-10S-0005 |
Inner Code | 766321 |
Description | piconet stand-alone module for PROFIBUS-DP 1-channel SSI Sensor Interface |
Technical specification | Ident no. 6824078 Number of channels 1 Operating / load voltage 20…29 VDC Operating current ð 140 mA Fieldbus transmission rate 9.6 kbps …12 Mbps Fieldbus addressing 0 to 99 Service interface parameterisation via I/O-ASSISTANT Electrical isolation Fieldbus to operational voltage Bit transfer differential (RS485) Transmission rate variable up to 1 MHz (default 250 Hz) Serial input 24 bit Data direction read Sensor supply 24 VDC from load voltage Potential separation operating voltage to RS232 Dimensions (W x L x H) 30 x 175 x 26.5 mm Vibration test Acc. to EN 60068-2-6 Shock test acc. to DIN EN 60068-2-27 Electromagnetic compatibility Acc. to EN 61000-6-2/EN 61000-6-4 Protection class IP67 Approvals CE, cULus |
Weight | 1 |
Please contact us to request a price quote for Turck - SDPB-10S-0005, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
