Turck - RM-89SA1R-9H28B-B2M12
| Manufacturer | Turck |
|---|---|
| Part Number | RM-89SA1R-9H28B-B2M12 |
| Inner Code | 762782 |
| Description | Absolute encoder |
| Technical specification | Manufacturer Part Number: 1562102 Main function: Encoder (Absolute) Functions: Absolute multi-turn encoder Design: solid shaft square flange optical sensing Supply voltage (DC): 11Vdc-25Vdc (12Vdc-24Vdc nom.) Rotational speed: 6000rpm max. Moment of inertia: 4 x 10-6kg.m2 Connection type: Pre-equipped with radial M12 Eurofast QD connectors x 2 Communication protocol: Ethernet/IP Mounting mode: 2.5" square flange mounting Resolution: 16-bit (single-turn) 12-bit (multi-turn) Degree of protection: IP67 Dimensions: H70mm x W70mm x D150mm 2.5" casing diameter 3/8" shaft diam. (D3/8") 7/8" shaft length (L7/8") Material: Aluminium housing Stainless steel shaft Aluminium flange Ambient air temperature for operation: -40...+85 °C Current consumption: 50mA (no load) Maximum radial load: 178 N Maximum axial load: 89 N Mechanical resistance: Shock resistance according to EN 60068-2-27 -- 50g; 11ms 20g vibration resistance |
| Weight | 1 |
Please contact us to request a price quote for Turck - RM-89SA1R-9H28B-B2M12, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
