Turck - RI360P0-EQR24M0-INCRX2-H1181
| Manufacturer | Turck |
|---|---|
| Part Number | RI360P0-EQR24M0-INCRX2-H1181 |
| Inner Code | 766031 |
| Description | Contactless Encoder with Stainless Steel Housing – Incremental: 1 … 5000 ppr Premium Line |
| Technical specification | ID 1590912 Measuring principle Inductive General data Max. Rotational Speed 10000 rpm Determined with standardized construction, with a steel shaft Ø 20 mm, L = 50 mm and reducer Ø 20 mm Starting torque shaft load (radial / axial) not applicable, because of contactless measuring principle Nominal distance 1.5 mm Repeat accuracy ≤ 0.01 % of full scale Linearity deviation ≤ 0.05 % f.s. Temperature drift ≤ ± 0.003 % / K Output type Incremental Resolution, incremental 1024 ppr Electrical data Operating voltage 10…30 VDC Residual ripple ≤ 10 % Uss Isolation test voltage ≤ 0.5 kV Short-circuit protection yes / Cyclic Wire breakage/Reverse polarity protection yes / yes (voltage supply) Pulse frequency max. 200 kHz Signal level high min. UB - 2 V Signal level low max. 2.0 V |
| Weight | 1 |
Please contact us to request a price quote for Turck - RI360P0-EQR24M0-INCRX2-H1181, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
