Turck - Q60VR3LAF1400 W/30
| Manufacturer | Turck |
|---|---|
| Part Number | Q60VR3LAF1400 W/30 |
| Inner Code | 765601 |
| Description | Photoelectric Sensor – Laser Sensor |
| Technical specification | Type Q60VR3LAF1400 W/30 ID 3071891 Optical data Function Proximity switch Operating mode Background suppression, adjustable Light type Red Wavelength 650 nm Laser class í 1 Range 200…1400 mm Electrical data Operating voltage 12…250 VDC Operating voltage 24…250 VAC DC rated operational current ≤ 200 mA No-load current ≤ 50 mA Output function Complementary contact, Relay output Switching frequency ≤ 33 Hz Readiness delay ≤ 1000 ms Response time typical < 15 ms Setting option Screw Adjustment Mechanical data Design Rectangular, Q60 Dimensions 60 x 25 x 75 mm Housing material Plastic, Thermoplastic material, Yellow Lens plastic, Acrylic Electrical connection Cable, 9 m, PVC Number of cores 4 Core cross-section 0.5 mm2 Ambient temperature -10…+45 °C Protection class IP67 Special features keep/defer Power-on indication LED, Green Switching state LED, Yellow Error indication LED Excess gain indication LED, green, flashing Tests/approvals MTTF 19 years acc. to SN 29500 (Ed. 99) 40 °C Approvals CE, cURus |
| Weight | 1 |
Please contact us to request a price quote for Turck - Q60VR3LAF1400 W/30, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
