Turck - Q45UBB63DAQ
| Manufacturer | Turck |
|---|---|
| Part Number | Q45UBB63DAQ |
| Inner Code | 765651 |
| Description | Ultrasonic sensor — reflective sensor from the object |
| Technical specification | ID:3044129 Ultrasound data Function Proximity switch Distance 100…1400 mm Ultrasound frequency 230 kHz Repeatability ≤ ± 1 mm Temperature deviation ≤ 0.13 % of final value/K electrical data Operating voltage 12…24 VDC Typical response time < 20 ms Output function NO contact, PNP/NPN Switching frequency ≤ 50 Hz Hysteresis ≤ 0.5 mm Short circuit protection yes / Cyclic Reverse polarity protection Complete Mechanical data Design Rectangle, Q45 Radiation direction is straight Dimensions 60.5 x 44.5 x 102.6 mm Housing material Plastic, PBT Transducer material Plastic, Epoxyd resin and PU foam Electrical connection Connectors, 7/8", 2 m, PVC Ambient temperature -25…+70 °C Relative humidity 100 % IP Rating IP67 Tests/approvals MTTF year 50 conforming to SN 29500 (Ed. 99) 40 °C Approvals CE |
| Weight | 1 |
Please contact us to request a price quote for Turck - Q45UBB63DAQ, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
