Turck - Q45UBB63DA
| Manufacturer | Turck |
|---|---|
| Part Number | Q45UBB63DA |
| Inner Code | 765650 |
| Description | Ultrasonic Sensor – diffuse mode sensor |
| Technical specification | ID 3044128 Ultrasonic data Function Proximity switch Range 100…1400 mm Ultrasound frequency 230 kHz Repeatability ≤ ± 1 mm Temperature drift ≤ 0.13 % of full scale/K Electrical data Operating voltage 12…24 VDC Response time typical < 20 ms Output function NO contact, PNP/NPN Switching frequency ≤ 50 Hz Hysteresis ≤ 0.5 mm Short-circuit protection yes / Cyclic Reverse polarity protection Complete Mechanical data Design Rectangular, Q45 Radiation direction straight Dimensions 60.5 x 44.5 x 87.6 mm Housing material Plastic, PBT Transducer material Plastic, Epoxyd resin and PU foam Electrical connection Cable, 2 m, PVC Ambient temperature -25…+70 °C Relative humidity 100 % Protection class IP67 Tests/approvals MTTF 50 years acc. to SN 29500 (Ed. 99) 40 °C Approvals CE |
| Weight | 1 |
Please contact us to request a price quote for Turck - Q45UBB63DA, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
