Turck - PVA225P6EQ
| Manufacturer | Turck |
|---|---|
| Part Number | PVA225P6EQ |
| Inner Code | 765716 |
| Description | Pick-to-Light – Placement Sensor Light Grid |
| Technical specification | ID 3051914 Signal and display data Purpose Pick-to-Light Function Opposed mode sensor Max. range 2000 mm Light type IR Scan field 225 mm Number of beams 10 Optical resolution 25 mm Switch Function Momentary Features of color 1 Green, Can be set via DIP switches Electrical data Operating voltage 12…30 VDC Max. current consumption per color 62 mA Input type Bipolar (PNP/NPN) Response time typical < 40 ms Mechanical data Design Rectangular, PVA Dimensions 266.4 x 30 x 15 mm Housing material Metal, AL, Black Window material Acrylic, clear Electrical connection Cable with connector, M12 × 1, 0.15 m, PVC Number of cores 4 |
| Weight | 1 |
Please contact us to request a price quote for Turck - PVA225P6EQ, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
