Turck - PT100R-29-LI3-H1140
| Manufacturer | Turck |
|---|---|
| Part Number | PT100R-29-LI3-H1140 |
| Inner Code | 765699 |
| Description | Pressure Transmitter, Front-Flush – With Current Output (2- Wire) |
| Technical specification | ID 6831559 Medium temperature -25…+85 °C Pressure range Pressure type Relative pressure Pressure range 0…100 bar 0…1450.38 psi 0…10 MPa Admissible overpressure ≤ 320 bar Burst pressure ≥ 640 bar Response time 1 ms Power supply Operating voltage 9…30 VDC Current consumption ≤ 4 mA Protective measure SELV according to EN 50178 Short-circuit/reverse polarity protection yes / yes Insulation class III Outputs Output 1 Analog output Output function Analog output current Analog output Current output 4…20 mA Load ≤ 1.2 kΩ Accuracy LHR ± 0.5 % FS BSL Housing material Stainless steel, 1.4435 (AISI 316L) |
| Weight | 1 |
