Turck - PT060R-29-LI3-H1140
| Manufacturer | Turck |
|---|---|
| Part Number | PT060R-29-LI3-H1140 |
| Inner Code | 765698 |
| Description | Pressure transmitter, front straight head — current output (2 wired) |
| Technical specification | ID:6831558 Ambient temperature -25…+85 °C Pressure range Pressure type Relative pressure Pressure range 0…60 bar 0…870.23 psi 0…6 MPa Acceptable overpressure ≤ 120 bar Burst pressure ≥ 360 bar Response time 1 ms power supply Operating speed ≥ 9…30 VDC Current consumption ≤ 4 mA Protective measure SELV according to EN 50178 Short circuit/Reverse polarity protection yes / yes Protection class III Outputs Output 1 analog output Output output Analog output current analog output Current output 4…20 mA Load ≤ 1.2 kΩ Accuracy LHR ± 0.5% FS BSL Body Stainless steel material, 1.4435 (AISI 316L) Process connection G 1/2" front flat head Material load connection Stainless steel 1.4435 (AISI 316L) |
| Weight | 1 |
Please contact us to request a price quote for Turck - PT060R-29-LI3-H1140, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
