Turck - PT040R-29-LI3-H1140
| Manufacturer | Turck |
|---|---|
| Part Number | PT040R-29-LI3-H1140 |
| Inner Code | 765697 |
| Description | Pressure Transmitter, Front-Flush – With Current Output (2- Wire) |
| Technical specification | ID 6831557 Medium temperature -25…+85 °C Pressure range Pressure type Relative pressure Pressure range 0…40 bar 0…580.15 psi 0…4 MPa Admissible overpressure ≤ 120 bar Burst pressure ≥ 360 bar Response time 1 ms Power supply Operating voltage 9…30 VDC Current consumption ≤ 4 mA Protective measure SELV according to EN 50178 Short-circuit/reverse polarity protection yes / yes Insulation class III Outputs Output 1 Analog output Output function Analog output current Analog output Current output 4…20 mA Load ≤ 1.2 kΩ Accuracy LHR ± 0.5 % FS BSL Housing material Stainless steel, 1.4435 (AISI 316L) |
| Weight | 1 |
Please contact us to request a price quote for Turck - PT040R-29-LI3-H1140, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
