Turck - p/n: 6870102, Type: FCS-G1/4A4-ARX-H1140
| Manufacturer | Turck |
|---|---|
| Part Number | p/n: 6870102, Type: FCS-G1/4A4-ARX-H1140 |
| Inner Code | 766521 |
| Description | Flow Monitoring – Immersion Sensor with Integrated Processor |
| Technical specification | Mounting conditions Immersion sensor Water Operating Range 1…150 cm/s Oil Operating Range 3…300 cm/s Stand-by time typ. 8 s (2…15 s) Switch-on time typ. 2 s (1…15 s) Switch-off time typ. 2 s (1…15 s) Temperature jump, response time max. 12 s Temperature gradient ≤ 250 K/min Medium temperature -20…+80 °C Electrical data Operating voltage 21.6…26.4 VDC Current consumption ≤ 70 mA Output function Relay output, NO contact Rated operational current 1 A Short-circuit protection no Reverse polarity protection yes AC switching voltage 30 VAC DC switching voltage 36 VDC Protection class IP67 Mechanical data Design Immersion Housing material Stainless steel, 1.4571 (AISI 316Ti) Sensor material Stainless steel, 1.4571 (AISI 316Ti) Max. tightening torque of housing nut 30 Nm |
| Weight | 1 |
Please contact us to request a price quote for Turck - p/n: 6870102, Type: FCS-G1/4A4-ARX-H1140, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
