Turck - NI35-CP40-VP4X2/S369-F 30M
| Manufacturer | Turck |
|---|---|
| Part Number | NI35-CP40-VP4X2/S369-F 30M |
| Inner Code | 765642 |
| Description | Inductive sensor |
| Technical specification | ID: 1569425 Special version S369 corresponds to: Ni / Bi…-CP40-…../S369-F o. T: with XX m ÖLFLEX rugged 215C 4x0.5 sw1-sw4 in SG40/2 potted (F=Front; T=Top) General data Nominal switching distance 35 mm Installation conditions Floating head Safe working distance ≤ (0.81 x Sn) mm Repetition precision ≤ 2 % of full scale Temperature deviation ≤ ±10% Hysteresis 3…15 % electrical data Operating voltage 10…65 VDC Stray surge ≤ 10 % Uss DC rated operating current ≤ 200 mA No-load current 15 mA Residual current ≤ 0.1 mA Insulation test voltage ≤ 0.5 kV Short circuit protection yes / Cyclic Voltage drop at Ie ≤ 1.8 V Wire break/Reverse polarity protection yes / Complete Output function 4-wire, Supplementary contact, PNP Protection class ÷ Switching frequency 0.15 kHz Mechanical data Design Rectangle, CP40 Dimensions 190 x 67 x 50 mm Body material Plastic, Ultem Active area material plastic, Ultem Electrical connection Cables Cable type Ø 6.6 mm, Ölflex resistant 215C, TPE, 30m Core cross-section 4 x 0.5 mm2 Ambient conditions Ambient temperature -25…+70 °C Vibration resistance 55 Hz (1 mm) Impact resistance 30 g (11 ms) IP Rating IP68 Power-on indicator 2 × LED, green Switching state 2 × LEDs, yellow |
| Weight | 1 |
