Turck - M18TIP6E
| Manufacturer | Turck |
|---|---|
| Part Number | M18TIP6E |
| Inner Code | 765704 |
| Description | Temperature sensor – Infrared sensor |
| Technical specification | ID no. 3081126 Measuring range 0…300 °C Temperature operating range -4…158 °F Factory setting -20…280 °C -4…536 °F Response time 75 ms Operating voltage 12…30 VDC Short-circuit/reverse polarity protection yes / Cyclic / yes Protection type and class IP67 Output 1 Analog output Output 2 switching output Output function NO contact, PNP/Analog output Current output 4…20 mA Response time typical < 75 ms Ambient temperature -20…+70 °C Storage temperature -20…+70 °C Housing Housing material Stainless steel, 1.4301 (AISI 304), Grey Process connection M18 × 1 Electrical connection Cable Cable quality Ø 6 mm, Black, PVC, 2 m, 2 m Core cross-section 5 x 0.5 mm2 Switching state LED, Yellow Included in delivery 2 M18 × 1 metal hexagon nuts |
| Weight | 1 |
