Turck - LX12ESRQ
| Manufacturer | Turck |
|---|---|
| Part Number | LX12ESRQ |
| Inner Code | 766054 |
| Description | Photoelectric Sensor |
| Technical specification | ID 3002686 Optical data Function Light screen Operating mode Emitter Light type IR Wavelength 880 nm Optical resolution 5.6 mm Range 75…200 mm Scan field 295 mm Electrical data Operating voltage 10…30 VDC Residual ripple < 10 % Uss No-load current ≤ 100 mA Short-circuit protection yes Reverse polarity protection yes Response time typical < 3.2 ms Mechanical data Design Rectangular, LX Dimensions 31.8 x 25.4 x 342 mm Housing material Metal, AL, Grey Lens plastic, Acrylic Electrical connection Cable with connector, M12 × 1, 0.15 m, PVC Number of cores 5 Core cross-section 0.5 mm2 |
| Weight | 1 |
Please contact us to request a price quote for Turck - LX12ESRQ, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
