Turck - LX12EQ
| Manufacturer | Turck |
|---|---|
| Part Number | LX12EQ |
| Inner Code | 766053 |
| Description | Photoelectric Sensor |
| Technical specification | ID:3002685 Optical data Function light curtain Operating mode Transmitter Light type IR Wavelength 880 nm Optical resolution 9.5 mm Distance 150…2000 mm Scanning area 295 mm electrical data Operating voltage 10…30 VDC Leakage surge < 10 % Uss No load current ≤ 100 mA Short circuit protection yes Reverse polarity protection yes Typical response time < 3.2 ms Mechanical data Design Rectangle, LX Dimensions 31.8 x 25.4 x 342mm Housing material Metal, AL, Gray Lens plastic, Acrylic Electrical connection Cable with connector, M12 × 1, 0.15 m, PVC Number of cores 5 Core cross section 0.5 mm2 Ambient temperature -20…+70 °C |
| Weight | 1 |
Please contact us to request a price quote for Turck - LX12EQ, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
