Turck - LS2LR30-150Q8
| Manufacturer | Turck |
|---|---|
| Part Number | LS2LR30-150Q8 |
| Inner Code | 766588 |
| Description | light screen for machine safety applications receiver |
| Technical specification | Type code LS2LR30-150Q8 Ident no. 3073554 Operating mode light screen Optical resolution 30 mm Range 200…15000 mm Detection zone height 150 mm Ambient temperature 0…+55 °C Operating voltage 20…28VDC Residual ripple < 15 % Uss No-load current I0 ð 90 mA Output function 2x NC, 2 x PNP Response time < 11 ms Design rectangular, EZ-Screen Dimensions 31.8 x 25.2 x 215 mm Housing material metal, AL, yellow Lens plastic, acrylic Connection male, M12 x 1 Protection class IP65 Power-on indication LED green Switching state LED red |
| Weight | 1 |
Please contact us to request a price quote for Turck - LS2LR30-150Q8, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
