Turck - LS2LP30-750Q88
| Manufacturer | Turck |
|---|---|
| Part Number | LS2LP30-750Q88 |
| Inner Code | 762602 |
| Description | Personal safety light curtain |
| Custom Code | 85365019900 |
| Technical specification | Transmitter/receiver pair Purchase order number: 3073568 Alternative order number: 73568 plug, M12 x 1, 8-pin Protection class IP65 Monitoring field height 750 mm resolution 30 mm Internal testing in a 500 ms cycle Range 15 m Operating voltage 24 VDC +‐ 15% Switch output with restart lock (LATCH) No muting support Type 2 in accordance with IEC 61496-1, -2; Category 2 PLd in accordance with EN ISO 13849-1; SIL2 in accordance with IEC 61508 Light curtain function Cuboid design Monitoring field height 750 mm Range 200... 15000 mm Optical resolution 30 mm Number of rays 40 Light type IR Cascadable - No With muting function - no Restart lock - yes Output function 2 x opener, 2 x PNP Electrical connection connector, M12 x 1 Case material - metal, AL, yellow polyester Ambient temperature 0... +55 °C Protection class IP65 |
| Weight | 1 |
Please contact us to request a price quote for Turck - LS2LP30-750Q88, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
