Turck - LS2E30-300Q8
| Manufacturer | Turck |
|---|---|
| Part Number | LS2E30-300Q8 |
| Inner Code | 765910 |
| Description | Light Screen for Machine Safety Applications – Emitter |
| Technical specification | ID 3073525 Optical data Function Light screen Light type IR Wavelength 950 nm Optical resolution 30 mm Range 200…15000 mm Scan field 300 mm Number of beams 16 With muting function no Scan Code None Electrical data Operating voltage 20…28 VDC Residual ripple < 15 % Uss DC rated operational current ≤ 50 mA No-load current ≤ 50 mA Response time typical < 13 ms Blanking function no Mechanical data Design Rectangular, EZ-Screen Dimensions 31.8 x 25.2 x 365 mm Housing material Metal, AL, Yellow polyester Lens plastic, Acrylic Cascadable No Electrical connection Connector, M12 × 1 Number of cores 8 |
| Weight | 1 |
Please contact us to request a price quote for Turck - LS2E30-300Q8, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
