Turck - LI100P1-Q25LM1-ELIUPN8X3-H1151
| Manufacturer | Turck |
|---|---|
| Part Number | LI100P1-Q25LM1-ELIUPN8X3-H1151 |
| Inner Code | 766062 |
| Description | Inductive Linear Position Sensor |
| Technical specification | ID no. 1590612 Measuring principle Inductive Measuring range 100 mm Resolution 16 bit Nominal distance 1.5 mm Blind zone a 29 mm Blind zone b 29 mm Reproducibility ≤ 18 µm Linearity deviation ≤ 0.12 %f.s. Temperature drift ≤ ± 0.003 % / K Hysteresis not applied Ambient temperature -25…+70 °C Operating voltage 15…30 VDC Residual ripple ≤ 10 % Uss Isolation test voltage ≤ 0.5 kV Short-circuit protection yes Wire breakage/Reverse polarity protection yes / Complete Communication protocol IO-Link Output function 5-pin, NO/NC, PNP/NPN, analog output Output 1 Switching output or IO-Link mode Output 2 analog or switching output Voltage output 0…10 V Current output 4…20 mA |
| Weight | 1 |
Please contact us to request a price quote for Turck - LI100P1-Q25LM1-ELIUPN8X3-H1151, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
