Turck - LI1000P1-Q25LM2-LIU5X3-H1151
| Manufacturer | Turck |
|---|---|
| Part Number | LI1000P1-Q25LM2-LIU5X3-H1151 |
| Inner Code | 765890 |
| Description | Inductive Linear Position Sensor |
| Technical specification | ID no. 1590130 Measuring principle Inductive Measuring range 100 mm Resolution 12 bit Nominal distance 1.5 mm Blind zone a 29 mm Blind zone b 29 mm Repeat accuracy ≤ 0.026 % of full scale Linearity deviation ≤ 0.12 %f.s. Temperature drift ≤ ± 0.003 % / K Hysteresis not applied Ambient temperature -25…+70 °C Operating voltage 15…30 VDC Residual ripple ≤ 10 % Uss Isolation test voltage ≤ 0.5 kV Short-circuit protection yes Wire breakage/Reverse polarity protection yes / yes (voltage supply) Output function 5-pin, Analog output Voltage output 0…10 V Current output 4…20 mA Load resistance voltage output ≥ 4.7 kΩ Load resistance, current output ≤ 0.4 kΩ Sample rate 500 Hz |
| Weight | 1 |
Please contact us to request a price quote for Turck - LI1000P1-Q25LM2-LIU5X3-H1151, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
