Turck - FCS-N1/2A4P-LIX-H1141/V300
| Manufacturer | Turck |
|---|---|
| Part Number | FCS-N1/2A4P-LIX-H1141/V300 |
| Inner Code | 765748 |
| Description | Flow Monitoring – Immersion Sensor with Integrated Processor |
| Technical specification | ID no. 6871047 Type FCS-N1/2A4P-LIX-H1141/V300 Mounting Immersion sensor Water Operating Range 5…300 cm/s Stand-by time ca. 10 s Setting time 1…15 s Medium temperature -20…+80 °C Ambient temperature -20…+70 °C Operating voltage 21.6…26.4 VDC Current consumption ≤ 100 mA Output function Analog output Short-circuit protection yes Reverse polarity protection yes Current output 4…20 mA Linearity deviation ≤ 10 % Load 200…500 Ω Protection class IP65 Design Immersion Housing material Plastic, PBT Sensor material Stainless steel, 1.4571 (AISI 316Ti) Max. tightening torque of housing nut 30 Nm Electrical connection Connector, M12 × 1 Process Pressure 100 bar Process connection 1/2" NPT |
| Weight | 1 |
Please contact us to request a price quote for Turck - FCS-N1/2A4P-LIX-H1141/V300, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
