Turck - FCS-N1/2A4-NAEX/D100
| Manufacturer | Turck |
|---|---|
| Part Number | FCS-N1/2A4-NAEX/D100 |
| Inner Code | 765838 |
| Description | Flow sensor — immersion type sensor without integrated processor |
| Technical specification | ID:6871427Special version D100 corresponds to: temperature range 10…120 °C Installation conditions Immersion sensor Water Operating Range 1…100 cm/s Oil Operating Range 3…200 cm/s Waiting time type. 8 sec (2…18 sec) Opening time type. 2 sec (1…13 sec) Shutdown time type. 2 sec (1…13 sec) Temperature jump, response time max. 12 sec Temperature gradient ≤ 250 K/min Ambient temperature 10…+120 °C electrical data Important note Regarding intrinsically safe applications In Ex certificates (ATEX, IECEX, UL etc.) specified values valid. Device marking É II 2 G Ex ib IIC T6 Gb É II 2 D Ex ib IIIC T125°C Db Fire protection category Gas Ex ib IIC; dust Ex ib IIIC Power ≤ 0.69 W Internal capacitance (Ci)/inductance (Li) Negligibly small Ex approval according to certificate of conformity TÜV 99 ATEX 1518 IP Rating IP67 Mechanical data Design Immersion |
| Weight | 1 |
