Turck - FCS-HA2P-LIX/AL115
| Manufacturer | Turck |
|---|---|
| Part Number | FCS-HA2P-LIX/AL115 |
| Inner Code | 765719 |
| Description | Flow sensor — Immersion sensor with integrated processor |
| Technical specification | ID:6870722 Type FCS-HA2P-LIX/AL115 Installation conditions Immersion sensor Air Operating Range 0.5…30 m/s Cooldown 20…90 sec Setting time 4…30 sec Temperature jump, response time max. 100 sec Temperature gradient ≤ 20 K/min Ambient temperature -20…+80 °C electrical data Current consumption ≤ 80 mA Output function Analog output Short circuit protection yes Reverse polarity protection yes Current output 4…20 mA Load 200…500 Ω conforming to MTBF 298SN 29500 (Bas. 99) 40°C Mechanical data Design Immersion Housing material Plastic, PBT Sensor material stainless steel, 1.4305 (AISI 303) Body nut max. tightening torque 30 Nm Electrical connection Cables Cable length 2 m Core cross-section 3 x 0.5 mm2 Compressive strength 3 bar Process connection G 1 inch female thread, DIN 3852 |
| Weight | 1 |
Please contact us to request a price quote for Turck - FCS-HA2P-LIX/AL115, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
