Turck - FCS-GL1/2A4P-LIX-H1141
| Manufacturer | Turck |
|---|---|
| Part Number | FCS-GL1/2A4P-LIX-H1141 |
| Inner Code | 765625 |
| Description | Flow Monitoring – Immersion Sensor with Integrated Processor |
| Technical specification | Type FCS-GL1/2A4P-LIX-H1141 Mounting conditions Immersion sensor Water Operating Range 5…150 cm/s Stand-by time approx. 10 s Setting time 1…15 s Medium temperature -20…+80 °C Ambient temperature -20…+70 °C Electrical data Operating voltage 19.2…28.8 VDC Current consumption ≤ 100 mA Output function Analog output Short-circuit protection yes Reverse polarity protection yes Current output 4…20 mA Linearity deviation ≤ 10 % Load 200…500 Ω Protection class IP65 Mechanical data Design Immersion Housing material Plastic, PBT Sensor material Stainless steel, 1.4571 (AISI 316Ti) Max. tightening torque of housing nut 30 Nm Electrical connection Connector, M12 × 1 Pressure resistance 100 bar Process connection G 1/2" long version Flow state display LED chain, red (1x), green (5x) LED display red = 4 mA 1x green > 4 mA 2x green > 8 mA 3x green > 12 mA 4x green > 16 mA 5x green = 20 mA Tests/approvals Approvals UL UL registration number E210608 |
| Weight | 1 |
