Turck - FCS-GL1/2A4-NAEX0
| Manufacturer | Turck |
|---|---|
| Part Number | FCS-GL1/2A4-NAEX0 |
| Inner Code | 766262 |
| Description | Flow Monitoring – Immersion Sensor without Integrated Processor |
| Technical specification | Type FCS-GL1/2A4-NAEX0 Mounting conditions Immersion sensor Water Operating Range 1…100 cm/s Oil Operating Range 3…200 cm/s Stand-by time typ. 8 s (2…15 s) Switch-on time typ. 2 s (1…13 s) Switch-off time typ. 2 s (1…13 s) Temperature jump, response time max. 12 s Temperature gradient ≤ 250 K/min Medium temperature -20…+60 °C Electrical data Important note For intrinsically safe applications, the values specified in the corresponding Ex certificates (ATEX, IECEX, UL, etc.) apply. Device marking É II 1 G Ex ia IIC T6…T3 Ga É II 1/2 G Ex ia IIC T6…T3 Ga/Gb É II 1 D Ex ia IIIC T125 °C Da Ignition protection category Gas Ex ia IIC; dust Ex ia IIIC Power ≤ 0.69 W Internal capacitance (Ci)/inductance (Li) Negligibly small Ex approval acc. to conformity certificate TÜV 99 ATEX 1517X Protection class IP67 Mechanical data Design Immersion Housing material Stainless steel, 1.4571 (AISI 316Ti) |
| Weight | 1 |
Please contact us to request a price quote for Turck - FCS-GL1/2A4-NAEX0, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
