Turck - FCS-G1/4A4-NAEX/D100
| Manufacturer | Turck |
|---|---|
| Part Number | FCS-G1/4A4-NAEX/D100 |
| Inner Code | 766462 |
| Description | Flow Monitoring – Immersion Sensor without Integrated Processor |
| Technical specification | ID 6870475 Type FCS-G1/4A4-NAEX/D100 Special version D100 corresponds to: temperature range 10…120 °C Mounting conditions Immersion sensor Water Operating Range 1…100 cm/s Oil Operating Range 3…200 cm/s Stand-by time typ. 8 s (2…15 s) Switch-on time typ. 2 s (1…13 s) Switch-off time typ. 2 s (1…15 s) Temperature jump, response time max. 12 s Temperature gradient ≤ 250 K/min Medium temperature 10…+120 °C Electrical data Device marking É II 2 G EEx ib IIC T6 Ignition protection category Ex ib IIC Power ≤ 0.69 W Internal capacitance (Ci)/inductance (Li) Negligibly small Ex approval acc. to conformity certificate TÜV 99 ATEX 1518 Protection class IP67 Mechanical data Design Immersion Housing material Stainless steel, 1.4571 (AISI 316Ti) Sensor material Stainless steel, 1.4571 (AISI 316Ti) Max. tightening torque of housing nut 30 Nm Electrical connection Cable |
| Weight | 1 |
Please contact us to request a price quote for Turck - FCS-G1/4A4-NAEX/D100, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
