Turck - FCS-G1/4A4-ARX/D518 0,3M
| Manufacturer | Turck |
|---|---|
| Part Number | FCS-G1/4A4-ARX/D518 0,3M |
| Inner Code | 765935 |
| Description | Flow Monitoring – Immersion Sensor with Integrated Processor |
| Technical specification | ID no. 6870109 Type FCS-G1/4A4-ARX/D518 0.3M Special version D518 corresponds to: Compact unit with 5 sec. switching delay Mounting Immersion sensor Water Operating Range 1…150 cm/s Oil Operating Range 3…300 cm/s Stand-by time typ. 8 s (2…15 s) Switch-on time typ. 2 s (1…13 s) Switch-off time typ. 2 s (1…15 s) Temperature jump, response time max. 12 s Temperature gradient ≤ 250 K/min Medium temperature -20…+80 °C Operating voltage 21.6…26.4 VDC Current consumption ≤ 70 mA Output function Relay output, NO contact Rated operational current 1 A Short-circuit protection no Reverse polarity protection yes AC switching voltage 30 VAC DC switching voltage 36 VDC Max. AC switching capacity 1000 VA Max. DC switching capacity 60 W Protection class IP68 |
| Weight | 1 |
Please contact us to request a price quote for Turck - FCS-G1/4A4-ARX/D518 0,3M, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
