Turck - FCS-G1/2A4P-LIX-H1141/V300
| Manufacturer | Turck |
|---|---|
| Part Number | FCS-G1/2A4P-LIX-H1141/V300 |
| Inner Code | 765746 |
| Description | Flow Monitoring |
| Technical specification | Flow Monitoring; Sensor for liquid media; Calorimetric principle; Adjustment via potentiometer; Status indicated via LED chain; DC 3-wire, 21.6…26.4 VDC; 4…20 mA analog output; Connector device, M12 × 1 Ident-No. 6870058 Mounting Immersion sensor Water Operating Range 1…150 cm/s Oil Operating Range 3…300 cm/s Stand-by time approx. 10 s Setting time 1…15 s Medium temperature -20…+70 °C Operating voltage 21.6…26.4 VDC Current consumption ð 100 mA Output function Analog output Short-circuit protection yes Reverse polarity protection yes Current output 4…20 mA Load 200…500 ò Protection class IP65 Design Immersion Housing material Plastic, PBT Sensor material Stainless steel, V4A (1.4571) Max. tightening torque housing nut 30 Nm Electrical connection Connector, M12 × 1 Pressure resistance 100 bar Process connection G ½“ Flow state display LED chain, red (1x), green (5x) LED display red = 4 mA 1x green > 4 mA 2x green > 8 mA 3x green > 12 mA 4x green > 16 mA 5x green = 20 mA |
| Weight | 1 |
Please contact us to request a price quote for Turck - FCS-G1/2A4P-LIX-H1141/V300, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
