Turck - FCS-G1/2A4-NAEX0/AL065
| Manufacturer | Turck |
|---|---|
| Part Number | FCS-G1/2A4-NAEX0/AL065 |
| Inner Code | 766188 |
| Description | Flow Monitoring – Immersion Sensor without Integrated Processor |
| Technical specification | ID 6870346 Type FCS-G1/2A4-NAEX0/AL065 Mounting conditions Immersion sensor Air Operating Range 2…25 m/s Stand-by time 10…40 s Switch-on time Typ. 5 s (2…30 s) Switch-off time Typ. 5 s (2…30 s) Temperature jump, response time max. 120 s Temperature gradient ≤ 1 K/min Medium temperature -20…+60 °C Electrical data Important note For intrinsically safe applications, the values specified in the corresponding Ex certificates (ATEX, IECEX, UL, etc.) apply. Device marking É II 1 G Ex ia IIC T4…T3 Ga É II 1/2 G Ex ia IIC T4…T3 Ga/Gb É II 1 D Ex ia IIIC T145 °C Da Ignition protection category Gas Ex ia IIC; dust Ex ia IIIC Power ≤ 0.69 W Internal capacitance (Ci)/inductance (Li) Negligibly small Ex approval acc. to conformity certificate TÜV 99 ATEX 1517X Protection class IP67 MTTF 546 years Mechanical data Design Immersion Housing material Stainless steel, 1.4571 (AISI 316Ti) |
| Weight | 1 |
Please contact us to request a price quote for Turck - FCS-G1/2A4-NAEX0/AL065, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
