Turck - FCI-TCD04A4P-AP8X-H1141
| Manufacturer | Turck |
|---|---|
| Part Number | FCI-TCD04A4P-AP8X-H1141 |
| Inner Code | 765759 |
| Description | Flow sensor — Internal line sensor with integrated processor |
| Technical specification | ID:6870656 Type FCI-TCD04A4P-AP8X-H1141 Installation conditions Inline sensor Flow operating range 0.001…0.2 l/min Cooldown 5…20 sec Opening time 0.5…3 sec Shutdown time 0.5…3 sec Temperature gradient ≤ 400 K/min Ambient temperature 0…+60 °C Ambient temperature 0…+60 °C electrical data Operating voltage 19.2…28.8 VDC Current consumption ≤ 50 mA Output function PNP, NO contact Rated operating current 0.2 A Voltage drop at Ie ≤ 1.5 V Short circuit protection yes Reverse polarity protection yes IP Rating IP67 Mechanical data Design Inner line Housing material Plastic, PBT Sensor material stainless steel, 1.4571 (AISI 316Ti) Electrical connection Connectors, M12 × 1 Compressive strength 1 bar Process connection Tube 4 mm Switching status LED chain, green / yellow / red |
| Weight | 1 |
Please contact us to request a price quote for Turck - FCI-TCD04A4P-AP8X-H1141, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
