Turck - DX99N2X1W2N0M2X0D1
| Manufacturer | Turck |
|---|---|
| Part Number | DX99N2X1W2N0M2X0D1 |
| Inner Code | 762682 |
| Description | Radio transmission system |
| Technical specification | Ident-No. 3014192 Radio type Short range Stationary installation Frequency range 2.402 - 2.483 GHz 2.4 GHz ISM band Number of radio channels 50 Channel width 1 MHz Frequency Hopping Spread Spectrum (FHSS) frequency spread method Interference threshold -20 dB Time slot width 7.8 ms Typical response time < 1000 ms max. range ð 3200 m Radiation power 18 dB/65 mW ERP Radiation power 20 dB/100 mW EIRP Number of channels 2/2 Input type NPN/0... 20 mA Number of channels - Output type - Type name DX80 Cuboid design Housing material metal, AL Ambient temperature -40... +65 °C Protection class IP68 Dimensions 127 x 145 x 125.5 mm Operating voltage 3.6... ð 5.5 VDC Operating voltage indicator LED, green Internal antenna ■ Aluminum housing ■ Integrated signal strength indicator ■ Configuration via DIP switches ■ Deterministic data transmission ■ FHSS frequency hopping method ■ TDMA time multiplexing method ■ Transmission power: 63 mW, 18 dBm conducted, ð 20 dBm EIRP ■ Internal battery supply ■ provides 10 V for connected sensors ■ Inputs: 2 x NPN, 2 x 0... 20 mA |
| Weight | 1 |
Please contact us to request a price quote for Turck - DX99N2X1W2N0M2X0D1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
