Turck - DW500-70-7E-H1141
| Manufacturer | Turck |
|---|---|
| Part Number | DW500-70-7E-H1141 |
| Inner Code | 765672 |
| Description | Draw-Wire – Analog |
| Technical specification | ID 1544534 Remark to product Turck description modified: previously DW…-H1141 Measuring range 500 mm Linearity deviation ≤ 0.1 % Operating voltage 12…30 VDC Short-circuit protection yes Wire breakage/Reverse polarity protection yes Output function 4-pin, Analog output Current output 4…20 mA Design Draw Wire Housing material Titanium anodized aluminium min. extension force 3.4 N max.extension force 4 N max. extension speed 8 m/s Pull acceleration max. 200 m/s2 wire material Stainless steel Electrical connection Connector, M12 × 1 Ambient temperature -20…+60 °C Protection class IP65 |
| Weight | 1 |
Please contact us to request a price quote for Turck - DW500-70-7E-H1141, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
