Turck - CABLE4X0.34-SH-PUR-BK-100M/TXL
| Manufacturer | Turck |
|---|---|
| Part Number | CABLE4X0.34-SH-PUR-BK-100M/TXL |
| Inner Code | 766265 |
| Description | Actuator and Sensor Cable, PUR – Bulk Cable |
| Technical specification | Type CABLE4X0.34-SH-PUR-BK-100M/TXL ID 6627958 Number of Pins 4 Cable Cable diameter Ø 5.3 mm ± 0.20 Cable length 100 m Cable jacket PUR, Black Core insulation PP Core cross-section 4 x 0.34 mm² Arrangement of strands 42 x 0.1 mm Core colors BN, WH, BU, BK Electrical properties at +20 °C Test voltage 2000 V Current 4 A Insulation resistance > 30.5 MΩ/km forward resistance max. 57 Ω/km Mechanical and chemical properties Bending radius (stationary installation) ≥ 5 x Ø Bending radius (flexible use) ≥ 10 x Ø Bending cycles ≥ 5 million Admissible acceleration max. 5 m/s² Admissible travel path, horizontal 5 m (at 5 m/s²) Admissible travel path, vertical 2 m (at 5 m/s²) Admissible traversing speed 3.3 m/s Torsional stress ± 180 °/m Ambient temperature range (stationary) -50 °C…+80 °C Ambient temperature range (In motion) -25 °C…+80 °C Ambient temperature during drag chain operation |
| Weight | 1 |
Please contact us to request a price quote for Turck - CABLE4X0.34-SH-PUR-BK-100M/TXL, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
