Turck - BLCDP-8M12LT-8DI-PD-4DO-2A-P
| Manufacturer | Turck |
|---|---|
| Part Number | BLCDP-8M12LT-8DI-PD-4DO-2A-P |
| Inner Code | 765616 |
| Description | BL compact Fieldbus Station for PROFIBUS-DP 8 Digital PNP Inputs and 4 Digital PNP Outputs |
| Technical specification | Ident no. 6811176 Nominal system voltage 24 VDC System power supply Via auxiliary power Voltage supply connection 2 x M12, 5-pin Admissible range Vi 18…30 VDC Nominal current Vi 200 mA Max. current Vi 2 A Admissible range Vo 18…30 VDC Nominal current Vo 100 mA Max. current Vo 4 A Fieldbus transmission rate 9.6 kbps …12 Mbps Adjustment transmission rate Automatic detection Fieldbus address range 0...99 Fieldbus addressing 2 dec. Rotary coding switches Fieldbus connection technology 2 × M12 5-pin, reverse-keyed Fieldbus termination External Service interface RS232 interface Digital inputs Input type PNP Type of input diagnostics Channel diagnostics Sensor supply (VSENS) 24 VDC, 100 mA short-circuit limiting Low level signal voltage < 4.5 VDC High level signal voltage 7…30 VDC Low level signal current < 1.5 mA High level signal current 2.1 … 3.7 mA Input delay 0.25 or 2.5 (configurable) ms Digital outputs Output type PNP Type of output diagnostics Channel diagnostics Sensor supply (VSENS) 24 VDC Output current per channel 2 A Output voltage 24 VDC from supply voltage Output delay 3 ms Load type Resistive, inductive, lamp load Load resistance, resistive > 12 ò Load resistance, inductive < 1.2 H Lamp load < 10 W Switching frequency, resistive < 200 Hz Switching frequency, inductive < 2 Hz Switching frequency, lamp load < 20 Hz Short-circuit protection yes Dimensions 168 x 71 x 32.5 mm Mounting 2 × 5.4 mm diameter holes, 1.7 Nm torque Weight 620 ± 20 g Housing material Glass fiber reinforced nylon, nickel-plated connector Housing color Black Material screw Nickel-plated brass Material label Polyester with polycarbonate overlay Ground label material Nickel-plated brass Protection class IP67 IP69K Ambient temperature -40…+70 °C Storage temperature -40…+85 °C Relative humidity 15…95 %, non-condensing Vibration test Acc. to IEC 61131-2 - up to 20 g (at 10 up to 150 Hz) For mounting on base plate or machinery Shock test acc. to IEC 61131-2 Electromagnetic compatibility Acc. to IEC 61131-2 Approvals and certificates CE, cULus |
| Weight | 1 |
Please contact us to request a price quote for Turck - BLCDP-8M12LT-8DI-PD-4DO-2A-P, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
