Turck - BI2-CRS232-ADZ30X2-B1131/S34
| Manufacturer | Turck |
|---|---|
| Part Number | BI2-CRS232-ADZ30X2-B1131/S34 |
| Inner Code | 766473 |
| Description | Inductive Sensor – For High Pressures |
| Technical specification | ID no. 4270093 Special version S34 corresponds to: Weld-field immune proximity sensors Rated switching distance 2 mm Mounting conditions Flush Secured operating distance ≤ (0.81 × Sn) mm Correction factors St37 = 1; Al = 0.3; stainless steel = 0.7; Ms = 0.4 Repeat accuracy ≤ 2 % of full scale Static pressure ≤ 200 bar Dynamic pressure ≤ 100 bar Admissible contact medium electrically conductive Temperature drift ≤ ± 10 % Hysteresis 3…15 % Ambient temperature -25…+70 °C Operating voltage 20…250 VAC Operating voltage 10…300 VDC AC rated operational current ≤ 400 mA DC rated operational current ≤ 300 mA Frequency ≥ 50…≤ 60 Hz Residual current ≤ 1.7 mA Isolation test voltage ≤ 1.5 kV Surge current ≤ 3 A (≤ 20 ms max. 5 Hz) Short-circuit protection yes / Latching |
| Weight | 1 |
Please contact us to request a price quote for Turck - BI2-CRS232-ADZ30X2-B1131/S34, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
