Trimod Besta - DAA 01 051
| Manufacturer | Trimod Besta |
|---|---|
| Part Number | DAA 01 051 |
| Inner Code | 2026614 |
| Description | level switch |
| Custom Code | 90261089 |
| Technical specification | Type for side mounting Nominal pressure PN 25, max. 25 bar Operating temperature 0°C to 120°C Ambient temperature 0°C to 70°C Density of liquid min. 0,75 kg/dm³ Operating differential 12mm Wetside material Stainless steel (CrNiMo) Flange material Stainless steel (CrNiMo) Switch housing material Sea water resistant die cast aluminium Flange dimensions 92 x 92 mm (PCD 92 mm) Bellow material Perbunan Switch element 2 x Microswitch SPDT, silver contacts Switch rating 250 VAC, 5A 30 VDC, 5A Enclosure IP 66 / IP67 Safety integrity level SIL2 Approvals ABS,BV,DNV,GL,LRS,PRS,RINA,MRS no Dual use Equipment |
| Weight | 3 |
Please contact us to request a price quote for Trimod Besta - DAA 01 051, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
