TRAMEC - EP-090-1-C-010-A-Q-AE19-P39-N-B5
| Manufacturer | TRAMEC |
|---|---|
| Part Number | EP-090-1-C-010-A-Q-AE19-P39-N-B5 |
| Inner Code | 4602811 |
| Description | planetary |
| Custom Code | 84834029 |
| Technical specification | gearbox size 90 reduction levels 1 coaxial C Ratio: 1 10:1 Output shaft (output shaft) Ø 22 mm Output flange Q, 90 mm square (center. 65 mm, hole mark 105 mm) Input shaft AE 19 mm Input flange P39, square 90 mm, (Centr. Ø 80 mm, hole crevice Ø 100 mm, drill diameter 6.5 mm) installation position B5 Nominal date i. intermittent (Interm. Outp. Torq.) 50 Nm Max. Resl. Mom. (Max. Accel. Outp. Torq.) 80 Nm Max. overload (Max. emerg. output torque) 160 Nm dyne. Efficiency (dynamic efficiency) Rd= 0.96 Bearing life 20000 h Gearbox backlash max. 8 ́ [arcmin] |
Please contact us to request a price quote for TRAMEC - EP-090-1-C-010-A-Q-AE19-P39-N-B5, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
