TRAMEC - EP-090-2-C-016-T-Q-AE19-P07-N-B5
| Manufacturer | TRAMEC |
|---|---|
| Part Number | EP-090-2-C-016-T-Q-AE19-P07-N-B5 |
| Inner Code | 4598144 |
| Custom Code | 84834029 |
| Technical specification | No. 19968 Planetary gearbox: EP Gear size —: 90 Steps—:2 Coaxial—: C reduction ratio x: 1—: 16:1 Output shaft —: diameter 19 mm Output flange —: Q, square 90 mm (central diameter 65 mm, hole diameter 105 mm, 4* diameter 7 mm) Input shaft —: AE 19 mm Input flange —: P07, square 100 mm, (Centr. Ø 95 mm, hole Ø 115 mm, drill diameter 8.5 mm) Installation position—: B5 Nominal date i. intermittent (Interm. Outp. Torq.): 75 Nm Max. Resl. Mom. (Max. accel. outp. torq.) —: 120 Nm Max. Overload (Max. emerg. output torque) —: 240 Nm dyne. Dynamic efficiency —: Rd= 0.93 Bearing life —: 20000 h Gearbox backlash —: max. 10 ́ [arcmin] Art.No.Internal. (Code) —: 2562626105/60N001 Lifetime lubrication |
Please contact us to request a price quote for TRAMEC - EP-090-2-C-016-T-Q-AE19-P07-N-B5, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
