TRAMEC - EP 90/1 2562420304
| Manufacturer | TRAMEC |
|---|---|
| Part Number | EP 90/1 2562420304 |
| Inner Code | 4289951 |
| Description | Planetary Gearbox |
| Custom Code | 84834029 |
| Technical specification | Planetary gearbox: EP Gear size ----------------: 90 Reduction levels (steps) --------------: 1 Coaxial ----------------------------------------------: C Reduction (ratio) x: 1 ----------------------: 3: 1 Output shaft -------------------: Ø 22 mm Output flange ----------------: A Ø 90 mm (Center Ø 68 mm, hole diameter Ø 80 mm, 4 * M6 * 12 mm) Input shaft -----------------------: AE 19 mm Input flange --------------------: P06, quadr. 90 mm, (Center Ø 80 mm, hole diameter Ø 100 mm, drill Ø 6.5 mm) Installation position ------------------------------------------------- : B5 Nominal torque i. Intermittent operation (Interm. Outp. Torq.): T2N = 50 Nm Max. Accel.mom. (Max. Accel. Outp. Torq.) ----: T2A = 80 Nm Max. Overload (Max. Emergency output torque): T2S = 160 Nm Dynamic efficiency --------: Rd = 0.96 Bearing life -------------: 20000 h Gear backlash ----------------------------: max. 8´ [arcmin] |
Please contact us to request a price quote for TRAMEC - EP 90/1 2562420304, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
