TR Electronic - CDV115M-00010

Manufacturer TR Electronic
Part Number CDV115M-00010
Inner Code 4754437
Description absolute encoder
Custom Code 90318020
Technical specification CDV115M*8192/4096PBS+SSI 85ZB20N STEPCOUNT_ENC1 8,192,000 REVOLUTIONS_ENC1 4,096,000 INTERFACE_ENC1 PROFIBUS DP+SSI CODE_ENC1 PROGRAMMABLE SUPPLY SPG_ENC1 11-27V OUTPUT LEVEL_ENC1 RS485 OPTION_ENC1 12MBAUD HEATING PNO PROFILE CLASS.2 PRESET 1 PRESET VIA PROFIBUS PROGRAMMABLE SOFTNR_ENC1 4376AA STEPCOUNT_ENC2 8,192,000 REVOLUTIONS_ENC2 4,096,000 INTERFACE_ENC2 SSI+INC CODE_ENC2 GRAY SUPPLY SPG_ENC2 11-27V OUTPUT LEVEL_ENC2 RS422 OPTION_ENC2 HEATER INK TRACKS 2048IMP (11-27V) K1+K2+NEG PRESET 1 PROGRAMMABLE PULSE NUMBER_ENC2 2048IMP (11-27V) CHANNEL NUMBER_ENC2 (K1/K2) +NEGATION SOFTNR_ENC2 437696 PROTECTION CLASS IP65 WORKING TEMPERATURE -40+70°C FLANGE TYPE ZB85 20NUT/40 SHAFT DESIGN CONNECTION TYPE 4XM16X1.5 RADIAL CONNECTION DIRECTION PLUG OCCUPANCY NUMBER TR-ECE-TI-DGB-0096 ENC STAINLESS STEEL CENTERING RING OPTION HD HOUSING HEATING PRESET 1 PROGRAMMABLE DRAWING NO. 04-CDV115M-M0001 VERSION NUMBER 000 AL: N ECCN: N

Please contact us to request a price quote for TR Electronic - CDV115M-00010, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

TR Electronic-CDV115M-00010 price
