Telco - p/n: 14137, Type: SSR 01-4-046-020-20-H-1D1-0.5-J8
| Manufacturer | Telco |
|---|---|
| Part Number | p/n: 14137, Type: SSR 01-4-046-020-20-H-1D1-0.5-J8 |
| Inner Code | 1386013 |
| Description | Industrial Light Curtain |
| Technical specification | Operation Mode Thru Beam Function Receiver Supply Voltage 12 - 30 V dc Active Height 385 mm Channel Spacing 20 mm Sensing Range 4 m Output Solid State Relay Output Status N.C. Housing 33 x 36 mm Length 460 mm Connection 0.5 m cable with 8 pin, M12 plug Features Cross/Parallel Beams Selectable and Blanking Function Technical Data Supply Voltage 12 - 30 V dc Reverse Polarity Protected Yes Short Circuit Protected Yes Current Consumption 50 mA Output Rating 200 mA Number of Channels 20 Number of Cross Scanning Beams 58 Number of Parallel Beams 20 Distance, Beams Pinch Point 10 mm Channel Spacing 20 mm Response Time Beams: Parallel 6,6 ms / Cross 9,0 ms Power On Indicator Green LED Output Indicator Yellow LED System Status Indicator Red LED Profile Dimensions (w x d) 33 x 36 mm Housing Material, Front Lens Polycarbonate Housing Material, Profile Aluminium (black anodised) Cable 8 x 0,2 mm² Cable Sleeve PVC Ø 5,9 mm Environmental Data Vibration 10 - 55 Hz, 0,5 mm Shock 30 g Operation Temperature -30 to +60 °C Storage Temperature -40 to +80 °C Sealing Class IP 67 Light Immunity 5˚ > 100 000 lux |
| Weight | 1 |
