Telco - p/n: 14022, Type: SST 01-10-054-048-10-H-1D1-0.5-J5
| Manufacturer | Telco |
|---|---|
| Part Number | p/n: 14022, Type: SST 01-10-054-048-10-H-1D1-0.5-J5 |
| Inner Code | 1386075 |
| Description | Industrial Light Curtain |
| Technical specification | SS 01 SPACESCAN™ SERIES Operation Mode Thru Beam Function Transmitter Supply Voltage 12 - 30 V dc Active Height 475 mm Channel Spacing 10 mm Sensing Range 10 m Housing 33 x 36 mm Length 540 mm Connection 0.5 m cable with 5 pin, M12 plug Technical Data Supply Voltage 12 - 30 V dc Reverse Polarity Protected Yes Current Consumption 100 mA Number of Channels 48 Number of Cross Scanning Beams 142 Number of Parallel Beams 48 Distance, Beams Pinch Point 5 mm Channel Spacing 10 mm Test Input Yes Power On Indicator Green LED Light Source Infrared (880 nm) Profile Dimensions (w x d) 33 x 36 mm Housing Material, Front Lens Polycarbonate Housing Material, Profile Aluminium (black anodised) Cable 5 x 0,2 mm² Cable Sleeve PVC Ø 5,9 mm Environmental Data Vibration 10 - 55 Hz, 0,5 mm Shock 30 g Operation Temperature -30 to +60 °C Storage Temperature -40 to +80 °C Sealing Class IP 67 |
| Weight | 1 |
Please contact us to request a price quote for Telco - p/n: 14022, Type: SST 01-10-054-048-10-H-1D1-0.5-J5, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
