TEKNIC - CPM-SDHP-N0563P-ELN
| Manufacturer | TEKNIC |
|---|---|
| Part Number | CPM-SDHP-N0563P-ELN |
| Inner Code | 4468003 |
| Description | motor |
| Technical specification | Motor Frame SizeNEMA 56 - 7.47 in (189.74 mm) sq. Length9.22 in (234.19 mm) Input Voltage Range Input Voltage for 5-wire systems100-240 VAC (1- or 3-phase) 300-415 VAC (3-phase, 5-wire) Peak Torque (@230 VAC 3-ph)4,652 oz-in (32.9 N-m) Cont. (RMS) Torque (@230 VAC 3-ph)1,147 oz-in (8.1 N-m) Max Speed (@230 VAC 3-ph)2760 RPM Achievable ResolutionEnhanced Option0.029 degrees Repeatability0.006 degrees Shaft Diameter0.625 in (15.88 mm) Weight25.0 lb (11.3 kg) Rotor Inertia103.4 oz-in² (18.9 kg-cm²) Logic Input Voltage Range4.0 to 28 VDC Maximum Radial Load170 lbf (756.2 N) Maximum Thrust Load40 lbf (177.9 N) in; 70 lbf (311.4 N) out Ambient Temperature1-40° to +70° C Ambient Humidity0-95%; non-condensing |
Please contact us to request a price quote for TEKNIC - CPM-SDHP-N0563P-ELN, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
