Tecnomatic Italia - PRE140199/3
| Manufacturer | Tecnomatic Italia |
|---|---|
| Part Number | PRE140199/3 |
| Inner Code | 4735414 |
| Technical specification | THERMOCOUPLE: TYPE: 2 X TYPE "T" CONNECTION: 3/4 IN NPTM TEMPERATURE RATING: -200 TO 10 DEG C JUNCTION: UNGROUNDED SPEC/STD: ANSI MC96.1 SHEATH DIAMETER: 6MM SHEATH MATERIAL: 304 SS COMP MAKER: TECNOMATIC,ITALY EQPT DRG NO: PRE140199/3 EQPT TAG NO: 5-C-TE-028/029/032/034/035/036/042/046/047/145 THERMOCOUPLE WITHOUT THERMOWELL BUT WITH 3/4 IN. SCH 80 TP304 NIPPLE, 3/4 IN. NPT SS 304 UNION AND IP 65 CONNECTION HEAD W/ TERMINAL BLOCK AS PER TECNOMATIC DRG. PRE140199/3 INSERTION LENGTH : 1500 MM (COPPER/CONSTANTAN) COMP MAKER:TECNOMATIC,ITALY EQUIPMENT TAG NO:5-C-TE-028/029/032/034/035/036/042/046/047/145 THERMOCOUPLE WITHOUT THERMOWELL BUT WITH,3/4IN. SCH 80 TP304 NIPPLE 3/4 IN. NPT SS 304 UNION AND,IP 65 CONNECTION HEAD W/TERMINAL BLOCK AS PER TECNOMATIC DRG. PRE140199/3 Class :THERMOCOUPLE CONNECTION TYPE :3/4IN MNPT INSERTION LENGTH :1500MM JUNCTION TYPE :UNGROUNDED SHEATH DIAMETER :OD 6MM SHEATH MATERIAL :STAINLESS STEEL 304 STANDARD :ANSI MC96.1 TEMPERATURE RANGE :-200 TO 10DEG.C TYPE :2XTYPE T |
Please contact us to request a price quote for Tecnomatic Italia - PRE140199/3, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
