Suhner - BEX 15-HSK 8 (HSK 50)
| Manufacturer | Suhner |
|---|---|
| Part Number | BEX 15-HSK 8 (HSK 50) |
| Inner Code | 206377 |
| Description | machining spindle |
| Technical specification | max. drilling capacity * 15 mm/600 N/mm² - max. transferable torque 55 Nm - Speed max. 23,000 min-¹ (reachable via frequency converter operation with 90 Hz) - Gates Profile 5MGT3 toothed belt drive - with barrier air connection on the clamping flange - concentricity accuracy 0.01 mm - HSK-50 tool holder - Standard Z-shape motor layout - Motor protection class IP 55 - motor power 0.75 kW/2,900 min-¹ or Motor power 0.55 kW/1,450 min-¹ - Spindle speed levels can be selected between 625 and 625 13,050 min-¹ - see technical data - Weight 20 kg - RAL 5012 |
| Weight | 1 |
Please contact us to request a price quote for Suhner - BEX 15-HSK 8 (HSK 50), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
