Suhner - QUILLmaster BEM 25 H ISO 30
| Manufacturer | Suhner |
|---|---|
| Part Number | QUILLmaster BEM 25 H ISO 30 |
| Inner Code | 205029 |
| Custom Code | 84594900 |
| Technical specification | bore capacity 25 mm/600 N/mm² - Max. Transferable torque 80 Nm - total stroke 125 mm - working stroke 125 mm - feed force at 30 bar 15,000 N - feed rate 4 m/min. - Return speed 3 m/min. - piston cross section flow 50.26 cm2 - piston cross section return 21.79 cm2 - Drive three-phase motor 1.5 kW/... min-¹ - concentricity 0.01 mm - Tool holder ISO 30 DIN 2080 - limit switch electric - Speed range selectable 360 to 5,800 min-1 - max. permissible speed 8,000 min-1 (accessible via separate frequency inverter) |
| Weight | 1 |
Please contact us to request a price quote for Suhner - QUILLmaster BEM 25 H ISO 30, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
