Stober - P731SGSS0030ME
| Manufacturer | Stober |
|---|---|
| Part Number | P731SGSS0030ME |
| Inner Code | 4304624 |
| Description | planetary gearbox with motor adapter |
| Custom Code | 84834021 |
| Technical specification | MV0000127206 translation 3,000 Math. Accurate translation 3/1 Rated torque 300 Nm max.perm. acceleration torque 500 Nm Max. input speed duration 2,200 rpm engine speed 1,500 rpm Max. input speed cycle 4,000 rpm Spin 3.0 arcmin load characteristic 1.0 solid shaft design without feather key shaft dimension Ø40x82 * Enclosure design ¡145 PR 130 LK 165 * Installation position arbitrary Shaft coupling clamping coupling design motorshaft diameter 38 without feather key Maximum motor wavelength min. 47 mm - max. 80 mm Clutch housing design two-piece (for engine plate) motor connection ¡190 180/215 M12 c=45 *215021 Access clamping screw 270° LUBRICATION MOBILE SHC 629 CLP HC ISO VG 150 Paintwork K /1-layer paint color RAL 9005 jet black downforce painting options not painted Documentation language German Documentation language English |
Please contact us to request a price quote for Stober - P731SGSS0030ME, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
