Stober - K302AG0074MQ30
| Manufacturer | Stober |
|---|---|
| Part Number | K302AG0074MQ30 |
| Inner Code | 3289887 |
| Description | bevel gear with motor adapter |
| Custom Code | 84834023 |
| Technical specification | Translation 7.391 Math. exact translation 473/64 Rated torque 250.0 Nm Max.perm. acceleration moment 375.0 Nm Max. input speed duration 2700 rpm engine speed 1500 rpm Max. input speed cycle 3800 rpm Spinning 4.0 arcmin load characteristic value 1.0 shaft design hollow shaft A Shaft dimension Ø 35 *90178 Position shaft/pinion insert side 4 housing design threaded hole circle mounting position EL2 shaft coupling type plug-in coupling GS motor shaft diameter GS28 shaft 32 without passf. * Maximum motor wavelength max. 60 mm clutch housing design one-piece motor connection Q190 130/215 13 c=122 *94510 Lubrication Mobilgear 600 XP 220 * CLP ISO VG 220 Spinning Game Spinning Game Reduced Class 2 Paint 2KG/2-Comp. primer color RAL 7001 silver grey painting options side 4 not painted Documentation language German, English |
| Weight | 32.2 |
Please contact us to request a price quote for Stober - K302AG0074MQ30, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
